Corsair - CORSAIR AX1600i
Power supply (internal) - ATX12V 2.4/ EPS12V 2.92 - 80 PLUS Titanium - AC 100-240 V - 1600 Watt - North America
Corsair
CP-9020087-NA
0843591050340
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | CORSAIR AX1600i - power supply - 1600 Watt |
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V 2.4/ EPS12V 2.92 |
| 80 PLUS Certification | 80 PLUS Titanium |
| Weight | 5.84 lbs |
| Localization | North America |
| Input Voltage | AC 100-240 V |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 1600 Watt |
| Output connectors | 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 8 x 8 pin PCI Express power with detachable 2 pin section ¦ 9 x 4 pin internal power ¦ 16 x 15 pin Serial ATA power ¦ 2 x 4 pin mini-power connector |
| Cooling System | 140 mm fan |
| Included Accessories | Case badge, cable ties, mounting kit, cable bag, magnetic side labels |
| Dimensions (WxDxH) | 5.9 in x 7.9 in x 3.4 in |
| Manufacturer Warranty | 10-year warranty |
| General | |
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V 2.4/ EPS12V 2.92 |
| PSU Form Factor | ATX |
| Localization | North America |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 10 years |
| Miscellaneous | |
| Included Accessories | Case badge, cable ties, mounting kit, cable bag, magnetic side labels |
| MTBF | 100,000 hours |
| Cooling System | 140 mm fan |
| Features | Corsair Link, overcurrent protection, Multi-GPU Technologies Supported, Zero RPM fan mode, fan speed control, fluid dynamic bearing cooling fan, switchable single/multi 12V rails, manual self-test, Totem-pole PFC Gallium Nitride (GaN) transistors, fully modular |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 8 x 8 pin PCI Express power with detachable 2 pin section ¦ 9 x 4 pin internal power ¦ 16 x 15 pin Serial ATA power ¦ 2 x 4 pin mini-power connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 1600 Watt |
| Output Current | +3.3V - 30 A ¦ +5V - 30 A ¦ +12V - 133.3 A ¦ -12V - 0.8 A ¦ +5VSB - 3.5 A |
| Efficiency | 94%+ |
| Modular Cable Management | Yes |
| 80 PLUS Certification | 80 PLUS Titanium |
| Dimensions & Weight | |
| Width | 5.9 in |
| Depth | 7.9 in |
| Height | 3.4 in |
| Weight | 5.84 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 15.7 in |
| Shipping Depth | 8.6 in |
| Shipping Height | 6.3 in |
| Shipping Weight | 11.35 lbs |
