QNAP Systems, Inc -
QNAP Systems, Inc
TVS-EC2480U-SAS-RP-8GE-R2-US
N/A
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | QNAP TVS-EC2480U-SAS-RP R2 - NAS server - 0 GB |
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 4U |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 24 (max) |
| Dimensions (WxDxH) | 17.4 in x 20.9 in x 6.9 in |
| Weight | 50.88 lbs |
| Localization | United States |
| Processor | 1 x Intel Xeon E3-1246V3 3.5 GHz (Quad-Core) |
| Storage Controller | RAID SATA 6Gb/s / SAS 12Gb/s - RAID 0, 1, 5, 6, 10, JBOD, 5 hot spare, 6 hot spare, 10 hot spare, 1 hot spare |
| Networking | 10Mb LAN, 100Mb LAN, GigE, 10 GigE |
| RAM | 8 GB |
| Power | AC 120/230 V (50/60 Hz) |
| Power Redundancy | Yes |
| System Requirements | UNIX, Linux, Microsoft Windows Server 2003, Apple MacOS X or later |
| General | |
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 4U |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 24 (max) |
| Width | 17.4 in |
| Depth | 20.9 in |
| Height | 6.9 in |
| Weight | 50.88 lbs |
| Localization | United States |
| Expansion / Connectivity | |
| Expansion Bays | 24 (total) / 24 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots | 1 (total) / 0 (free) x PCI Express 3.0 x8 ¦ 1 (total) / 1 (free) x PCI Express 3.0 x4 ¦ 4 (total) / 2 (free) x DIMM 240-pin |
| Interfaces | 4 x USB 2.0 - Type A ¦ 4 x Ethernet 1000Base-T - RJ-45 ¦ 4 x USB 3.0 - Type A ¦ 2 x Ethernet 10Gb - SFP+ ¦ 1 x SAS 12Gb/s |
| Miscellaneous | |
| Cables Included | 4 x network cable |
| Features | Audible alarm, built-in 4 cooling fans |
| Compliant Standards | FIPS 140-2 |
| Included Accessories | Rack mounting kit |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE, 10 GigE |
| Network / Transport Protocol | TCP/IP, iSCSI, SMTP, FTP, DHCP, Bonjour, SMB, DDNS |
| Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH |
| Network Services Compatibility | Microsoft Active Directory (AD), Apple Bonjour Protocol, DHCP, DDNS, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV) |
| Features | VPN support, trunking, ALERT notification, LDAP support, wake on LAN (WOL), Syslog support, E-mail alert, print server, IPv6 support, antivirus analysis, IP address filtering, firmware upgradable, proxy server, MySQL server, web server, backup server, download client, file sharing, event log, Trivial File Transfer Protocol (TFTP) support, RADIUS support, SSH support, Jumbo Frames support, DHCP server, FTP server, SMS alert, UPnP Media Server, Network Access Protection (NAP), bandwidth control, IPv4 support, surveillance station, teaming support, PXE support, Apple Time Machine compatible, Link Aggregation Control Protocol (LACP), TFTP server, DHCP client, e-mail notification, cloud backup, VPN Server |
| Encryption Algorithm | SSL, 256-bit AES |
| Compliant Standards | IEEE 802.3ad (LACP), IEEE 802.1x, UPnP |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 650 Watt |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| OS Required | UNIX, Linux, Microsoft Windows Server 2003, Apple MacOS X or later |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 10 hot spare, RAID 1 hot spare |
| Processor / Memory | |
| Processors Installed | 1 x Intel Xeon E3-1246V3 3.5 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| RAM | 8 GB (installed) / 32 GB (supported) - DDR3 |
| Flash Memory Installed | 512 MB |
