QNAP Systems, Inc -
QNAP Systems, Inc
TS-1677X-1200-4G-US
0885022015115
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | QNAP TS-1677X - NAS server - 0 GB |
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 16 (max) |
| Dimensions (WxDxH) | 14.6 in x 12.6 in x 12 in |
| Weight | 29.52 lbs |
| Localization | United States |
| Processor | 1 x AMD Ryzen 3 1200 3.1 GHz (Quad-Core) |
| Storage Controller | RAID SATA 6Gb/s - RAID 0, 1, 5, 6, 10, 50, JBOD, 5 hot spare, 6 hot spare, 60, 50 hot spare, 10 hot spare, 60 hot spare |
| Networking | 10Mb LAN, 100Mb LAN, GigE, 10 GigE, 5 GigE, 2.5 GigE |
| IP Cameras Supported | 3000 |
| RAM | 4 GB |
| Power | AC 120/230 V (50/60 Hz) |
| Storage Operating System | QNAP QTS 4.3.4 |
| System Requirements | UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016 |
| General | |
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 16 (max) |
| Width | 14.6 in |
| Depth | 12.6 in |
| Height | 12 in |
| Weight | 29.52 lbs |
| Built-in Devices | Speaker, status LCD |
| Localization | United States |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" ¦ 4 (total) / 4 (free) x hot-swap - 2.5" |
| Expansion Slots | 4 (total) / 3 (free) x DIMM 288-pin ¦ 1 x PCI Express 3.0 x8 ¦ 1 x PCI Express 3.0 x4 ¦ 1 x PCI Express 2.0 x4 |
| Interfaces | 2 x Ethernet 10Gb - RJ-45 ¦ 4 x Ethernet 1000Base-T - RJ-45 ¦ 7 x USB 3.0 - Type A ¦ 1 x USB 3.0 - Type C ¦ 2 x microphone - mini-jack ¦ 1 x audio out - mini-jack |
| Miscellaneous | |
| Cables Included | 2 x network cable |
| Features | Security lock slot (cable lock sold separately), built-in 3 cooling fans |
| Security Slot Type | Kensington security slot |
| Compliant Standards | FIPS 140-2, AES-256, SSL |
| Included Accessories | Screws |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE, 10 GigE, 5 GigE, 2.5 GigE |
| Network / Transport Protocol | TCP/IP, PPTP, L2TP, IPSec, iSCSI, SMTP, FTP, DHCP, SMB, DDNS |
| Remote Management Protocol | SNMP 2, SNMP, Telnet, SNMP 3, HTTP, HTTPS, SSH |
| Network Services Compatibility | Microsoft Active Directory (AD), DHCP, DDNS, Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV) |
| Features | NAT support, VPN support, LDAP support, wake on LAN (WOL), Syslog support, E-mail alert, IPv6 support, firmware upgradable, proxy server, Spanning Tree Protocol (STP) support, backup server, download client, file sharing, event log, Trivial File Transfer Protocol (TFTP) support, SSH support, iTunes server, Jumbo Frames support, DHCP server, FTP server, SMS alert, BitTorrent Client, Network Access Protection (NAP), bandwidth control, IPv4 support, surveillance station, teaming support, DLNA Media Server, Apple Time Machine compatible, DHCP client, e-mail notification, cloud backup, VPN Server, Apple AirPlay, Dropbox support, Real-time Remote Replication (RTRR), Google Drive support, Amazon Cloud Drive support, Yandex Disk support, Microsoft OneDrive support, DLNA support, Chromecast support, file station, hubiC support, OpenStack Swift-compatible, WebDAV server support, port trunking, Microsoft Azure support, Amazon S3 support, Amazon Glacier suport, HiDrive support, RTRR server, RTRR client |
| Encryption Algorithm | AES-NI |
| Compliant Standards | UPnP |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 550 Watt |
| Software / System Requirements | |
| Storage Operating System | QNAP QTS 4.3.4 |
| OS Required | UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 60, RAID 50 hot spare, RAID 10 hot spare, RAID 60 hot spare |
| Processor / Memory | |
| Processors Installed | 1 x AMD Ryzen 3 1200 3.1 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 3.4 GHz |
| RAM | (supported) 4 GB (installed) / 64 GB (supported) - DDR4 |
| Security DVR | |
| IP Cameras Supported | 3000 |
